Challenge JF Single Spindle Drill

GM-CMC-JF

Item Availability (unit) Ea. (1)

A manual, foot pedal operated drill with 2" drilling capacity. Auto-trip side guide for multi-hole patterns.

• 2" Drilling Capacity
• 13 Hollow Drill Bit Sizes
• Foot Pedal Operation
• Automatic Paper Chip Removal

POA

Qty:

Description

• 2" Drilling Capacity
• 13 Hollow Drill Bit Sizes
• Foot Pedal Operation
• Automatic Paper Chip Removal
• Adjustable Margins
• Auto Trip Side Guide
• Built to Last

Specifications

Drill Head Operation	Foot Pedal
Drill Sizes Available	1/8" to 1/2" / 3 to 13 mm
Maximum Drilling Capacity	2" / 51 mm
Minimum Distance Between Holes w/ Adj. Stops	3/8" / 9.5 cm
Minimum Distance Between Holes w/ Fixed Gauges	1/4" / 6 mm
Adjustable Range - Drill to Side Guide	0 to 18-1/2" / 0 - 47 cm
Adjustable Range - Drill to Backgauge	0 to 4" / 0 - 10 cm
Side Guide Trip	Automatic
Cornering Capacity	1/2" / 13 mm
Cornering Capacity (with Cornermatic)	1" / 2.5 cm
Slit / V-slot Capacity	1/2" / 13 mm

DIMENSIONS

Table Size	19-1/2" x 31-1/2" / 49.5 x 80 cm
Table Height	38" / 97 cm
Overall Height	60" / 152 cm
Floor Space Needed	32" x 42" / 81 x 107 cm
Net Weight (approximate)	154 lbs / 69 kg
Shipping Weight (approximate)	178 lbs / 80 kg
